| صورة | نموذج | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Master H 25-7.5 Pro | 25 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 60 | 130/180 | G 1 1/2 |
|
Master H 20-7.5 Pro | 20 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 60 | 130 | G 1 |
|
Master H 25-6 Pro | 25 | 2 | 3.2 | 6 | 220~240 | 50/60 | 39 | 130/180 | G 1 1/2 |
|
Master H 20-6 Pro | 20 | 2 | 3.3 | 6 | 220~240 | 50/60 | 39 | 130 | G 1 |
 |
Basic 20-35SZ | 20 | 5 | 25 | 30 | 230/380 | 50 | 1300/1100/800 | 295 | G1 |
 |
Basic 20-26SZ | 20 | 7 | 18 | 26 | 230/380 | 50 | 1000/860/580 | 268 | G1 |
 |
Basic 25-20SZ | 25 | 9 | 14 | 20 | 230/380 | 50 | 1000/770/670 | 268 | G1 1/2 |
 |
Basic 20-20SZ | 20 | 5 | 16 | 20 | 230/380 | 50 | 700/550/410 | 272 | G1 |
