| صورة | نموذج | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Mega 25-10 | 25 | 5 | 6.5 | 10 | 230 | 50/60 | 185 | 180 | G1 1/2 |
 |
Mega 25-8 | 25 | 4 | 5.5 | 8 | 230 | 50/60 | 130 | 180 | G1 1/2 |
 |
Mega 25-6 | 25 | 4 | 3.5 | 6 | 230 | 50/60 | 90 | 180 | G1 1/2 |
 |
Mega 25-12 | 25 | 5.5 | 7.5 | 12 | 220~240 | 50/60 | 230 | 180 | DN25 |
|
Mega 32-12 | 25 | 5.5 | 7.5 | 12 | 220~240 | 50/60 | 230 | 180 | DN25 |
 |
Mega 40-12F | 40 | 6 | 6.5 | 12 | 230 | 50/60 | 250 | 220 | /Flange |
 |
Mega 40-10F | 40 | 5 | 6 | 10 | 230 | 50/60 | 185 | 220 | /Flange |
 |
Mega 32-6 | 32 | 4 | 3.5 | 6 | 230 | 50/60 | 90 | 180 | G2 |
 |
Mega 32-8 | 32 | 4 | 5.5 | 8 | 230 | 50/60 | 130 | 180 | G2 |
 |
Mega 32-10 | 32 | 5.5 | 5.5 | 10 | 230 | 50/60 | 185 | 180 | G2 |
 |
Mega 40-6F | 40 | 4 | 3.7 | 6 | 230 | 50/60 | 90 | 220 | /Flange |
 |
Mega 40-8F | 40 | 5 | 4.2 | 8 | 230 | 50/60 | 130 | 220 | /Flange |
