| صورة | نموذج | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
EPS25-40NC | 25 | 6 | 30 | 42 | 380 | 50 | 1300 | 393 | Chuck |
|
EPS25-30NC | 25 | 5 | 25 | 30 | 380 | 50 | 1000 | 359 | Chuck |
 |
EPA 50-30ZAX | 50 | 20 | 25 | 30 | 380 | 50 | 3000 | 274.8 | Chuck |
 |
EPA 50-30ZA | 50 | 20 | 25 | 30 | 380 | 50 | 3000 | 321.5 | Chuck |
 |
EPA 25-20ZA | 25 | 3 | 17 | 20 | 250 | 50/60 | 350 | 208 | Chuck |
|
EPA 25-20ZAX | 25 | 3 | 16 | 20 | 270 | 50 | 350 | 168 | Chuck |
 |
Mega S 32-12 Pro | 32 | 5.5 | 7.5 | 12 | 220~240 | 50/60 | 220 | 180 | G2 |
 |
Mega S 25-12 Pro | 25 | 5.5 | 7.5 | 12 | 220~240 | 50/60 | 220 | 180 | G1 1/2 |
 |
Mega S 32-12F Pro | 32 | 11 | 7 | 12 | 220~240 | 50/60 | 400 | 180 | G2 |
 |
Grand 32-17 Pro | 32 | 5 | 12 | 17 | 220~240 | 50/60 | 350 | 180 | G 2 |
 |
Grand 25-17 Pro | 25 | 5 | 12 | 17 | 220~240 | 50/60 | 350 | 180 | G 1 1/2 |
 |
Grand 32-15 Pro | 32 | 5.5 | 11 | 15 | 220~240 | 50/60 | 300 | 180 | G2 |
 |
Grand 25-15 Pro | 25 | 5.5 | 11 | 15 | 220~240 | 50/60 | 300 | 180 | G 1 1/2 |
 |
Grand 32-13 Pro | 32 | 4 | 8 | 13 | 220~240 | 50/60 | 195 | 180 | G2 |
 |
Grand 25-13 Pro | 25 | 4 | 8 | 13 | 220~240 | 50/60 | 195 | 130/180 | G 1 1/2 |
 |
Grand 32-11 Pro | 32 | 3.5 | 8 | 11 | 220~240 | 50/60 | 160 | 180 | G2 |
 |
Master H 20-9 Pro | 20 | 2.5 | 6.5 | 9 | 220~240 | 50/60 | 95 | 130 | G 1 |
 |
Master H 25-7.5 Pro | 25 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 60 | 130/180 | G 1 1/2 |
 |
Master H 20-7.5 Pro | 20 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 60 | 130 | G 1 |
 |
Master H 25-6 Pro | 25 | 2 | 3.2 | 6 | 220~240 | 50/60 | 39 | 130/180 | G 1 1/2 |
 |
Master H 20-6 Pro | 20 | 2 | 3.3 | 6 | 220~240 | 50/60 | 39 | 130 | G 1 |
 |
Basic 20-35SZ | 20 | 5 | 25 | 30 | 230/380 | 50 | 1300/1100/800 | 295 | G1 |
 |
Basic 20-26SZ | 20 | 7 | 18 | 26 | 230/380 | 50 | 1000/860/580 | 268 | G1 |
 |
Basic 25-20SZ | 25 | 9 | 14 | 20 | 230/380 | 50 | 1000/770/670 | 268 | G1 1/2 |
 |
Basic 20-20SZ | 20 | 5 | 16 | 20 | 230/380 | 50 | 700/550/410 | 272 | G1 |
 |
Basic 25-16SZ | 25 | 7 | 12.5 | 16 | 230/380 | 50 | 700/550/410 | 222 | G1 1/2 |
 |
Basic 20-16SZXL | 20 | 3 | 11.5 | 16 | 230 | 50 | 500/460/440 | 222 | G1 |
 |
Basic 25-12SZXL | 25 | 5 | 8.5 | 12 | 230 | 50 | 500/460/440 | 229 | G1 1/2 |
 |
Basic 25-9SZXL | 25 | 5 | 5 | 9 | 230 | 50 | 300/280/260 | 209 | G1 1/2 |
 |
Basic 20-12SZXL | 20 | 5 | 2 | 10 | 230 | 50 | 300/280/260 | 202 | G1 |
