| صورة | نموذج | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Basic 25-16S | 25 | 7 | 12.5 | 16 | 380 | 50 | 700 | 230 | G1 1/2 |
 |
Basic 25-20S | 25 | 9 | 14 | 20 | 380 | 50 | 1000 | 230 | G1 1/2 |
 |
Basic S 25-4S | 25 | / | / | 4 | 230 | 50 | 50/40/30 | 130/180 | G1 1/2 |
 |
Basic S 25-5S | 25 | / | / | 5 | 230 | 50 | 65/50/40 | 130/180 | G1 1/2 |
 |
Basic S 25-6S | 25 | / | / | 6 | 230 | 50 | 70/60/50 | 130/180 | G1 1/2 |
 |
Basic S 25-7S | 25 | / | / | 6.5 | 230 | 50 | 100/80/60 | 130/180 | G1 1/2 |
 |
Basic S 25-8S | 25 | / | / | 8 | 230 | 50 | 180/175/130 | 180 | G1 1/2 |
 |
PFB 06-22 Pro | 25 | 6 | 22 | 28 | 220~240 | 50 | 700 | 260 | G1 |
 |
PFB 06-22 EC | 25 | 6 | 22 | 28 | 220 | 50 | 700 | 260 | G1 |
 |
PFM03-30EC Pro | 25 | 3 | 30 | 45 | 220 | 50 | 600 | 200 | G1 |
 |
PFM03-30 EC | 25 | 3 | 30 | 45 | 220 | 50 | 600 | 200 | G1 |
 |
PUN-200L | 25 | 2 | 10 | 15 | 220 | 50 | 320 | 253 | G1 |
 |
PUN-401 | 25 | 3 | 15 | 21 | 220 | 50 | 660 | 283 | G1 |
|
PUN-600 | 25 | 3 | 20 | 25 | 220 | 50 | 880 | 306 | G1 |
|
PUN-600 | 25 | 3 | 20 | 25 | 380 | 50 | 880 | 306 | G1 |
 |
PH-041 | 25 | 2 | 2.5 | 3.5 | 220 | 50/60 | 90 | 216 | G1 |
 |
MHI-201 | 25/25 | 2 | 9.5 | 11 | 220 | 50 | 250 | 373 | Rp1-Rp1 |
|
MHI-202 | 25/25 | 2 | 18 | 20 | 220 | 50 | 550 | 375 | Rp1-Rp1 |
|
MHI-203 | 25/25 | 2 | 28 | 33 | 220 | 50 | 780 | 375 | Rp1-Rp1 |
 |
MHI-203Q | 25/25 | 2 | 28 | 33 | 380 | 50 | 780 | 375 | Rp1-Rp1 |
|
MHI-403 | 32/25 | 4 | 28 | 33 | 220 | 50 | 780 | 371 | Rp1 1/4-Rp1 |
 |
MHI-403Q | 32/25 | 4 | 28 | 33 | 380 | 50 | 780 | 371 | Rp1 1/4-Rp1 |
|
MHI-404 | 32/25 | 4 | 35 | 42 | 220 | 50 | 980 | 448 | Rp1 1/4-Rp1 |
 |
MHI-404Q | 32/25 | 4 | 35 | 42 | 380 | 50 | 980 | 448 | Rp1 1/4-Rp1 |
|
MHI-405 | 32/25 | 4 | 46 | 57 | 220 | 50 | 1350 | 448 | Rp1 1/4-Rp1 |
 |
MHI-405Q | 32/25 | 4 | 46 | 57 | 380 | 50 | 1350 | 448 | Rp1 1/4-Rp1 |
 |
F-MHI403Q | 32/25 | 4 | 25 | 33 | 220 | 50 | 800 | 525 | Rp1 1/4-Rp1 |
|
F-MHI405Q | 32/25 | 4 | 50 | 57 | 220 | 50 | 1350 | 565 | Rp1 1/4-Rp1 |
|
F-MHI404Q | 32/25 | 4 | 38 | 42 | 220 | 50 | 980 | 525 | Rp1 1/4-Rp1 |
 |
GPD 25-12F | 36 | 36 | 110 | 60 | 335 | 6 1/2 | Flanged |
