| صورة | نموذج | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Basic 65-12F | 65 | 25 | 7.5 | 12 | 230 | 50/60 | 1300 | 300/340 | DN65 |
 |
Basic 80-12F | 80 | 28 | 7 | 12 | 230 | 50/60 | 1300 | 360 | DN80 |
 |
Basic 25-16S | 25 | 7 | 12.5 | 16 | 380 | 50 | 700 | 230 | G1 1/2 |
 |
Basic 40-12SF | 40 | 8 | 10 | 12 | 380 | 50 | 700 | 250 | DN40 |
 |
Basic 50-12SF | 50 | 15 | 9 | 12 | 380 | 50 | 1000 | 280 | DN50 |
 |
Basic 40-6F | 40 | 12.5 | 4.5 | 6 | 230 | 50 | 500 | / | / |
 |
SPA15-12E | 15 | 0.3 | 11 | 12 | 24 | 50/60 | 45 | 90 | G 1/2 |
 |
MHI-803Q | 40/32 | 8 | 28 | 35 | 380 | 50 | 1350 | 410 | Rp1 1/2- Rp1 1/4 |
 |
Basic 15-4SFC | 17.5 | 15.5 | 110 | 60 | 85 | 6 1/2 | Flanged | ||
 |
Basic 15-6SFC | 17 | 19 | 110 | 60 | 100 | 6 1/2 | Flanged | ||
 |
Basic 25-12F | 36 | 36 | 110 | 60 | 335 | 6 1/2 | Flanged | ||
 |
Basic 25-10SFC | 32 | 30 | 110 | 60 | 200 | 6 1/2 | Flanged | ||
 |
Basic 15-6SFRC | 17 | 19 | 110 | 60 | 100 | 6 1/2 | Flng-R | ||
 |
Basic 15-4SFRC | 17.5 | 15.5 | 110 | 60 | 85 | 6 1/2 | Flng-R | ||
 |
Basic 25-7.5SFC | 27 | 27 | 110 | 60 | 185 | 6 1/2 | Flanged | ||
 |
Basic 25-12U | 19 | 38 | 110 | 60 | 230 | 7 1/16 | 1 1/4 |
