| صورة | نموذج | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
GPA15-6 III U Z108 | 15 | 1 | 4 | 6 | 220~240 | 50/60 | 39 | 158 | DN15 |
 |
GPA15-7 III U Z108 | 15 | 1 | 5.5 | 7 | 220~240 | 50/60 | 52 | 158 | DN15 |
 |
GPA15-7.5 III U Z108 | 15 | 1 | 6.5 | 7.5 | 220~240 | 50/60 | 60 | 158 | DN15 |
 |
GPA15-5 III U Z107 | 15 | 1 | 3.5 | 5 | 220~240 | 50/60 | 33 | 158 | DN15 |
 |
GPA15-7 III U Z107 | 15 | 1 | 5.5 | 7 | 220~240 | 50/60 | 52 | 158 | DN15 |
 |
GPA15-6 III U Z107 | 15 | 1 | 4 | 6 | 220~240 | 50/60 | 39 | 158 | DN15 |
 |
GPA15-7.5 III U Z107 | 15 | 1 | 6.5 | 7.5 | 220~240 | 50/60 | 60 | 158 | DN15 |
 |
SPA 15-12E | 15 | 0.6 | 8 | 12 | 220 | 50/60 | 60 | 140 | G 3/4 |
 |
Basic 32-8SN | 32 | 4 | 5.5 | 8 | 115/230 | 50/60 | 245/190/135 | 180 | G2 |
 |
Basic 25-5SB | 25 | 1.8 | 3.2 | 5 | 115/230 | 50/60 | 85/60/40 | 130 | G1 1/2 |
 |
Master H 25-9 Pro | 25 | 4.5 | 6.5 | 9 | 220~240 | 50/60 | 95 | 130/180 | G 1 1/2 |
 |
Basic 25-5S | 25 | 1.8 | 3.2 | 5 | 115/230 | 50/60 | 85/60/40 | 130/180 | G1 1/2 |
 |
Instant Pro 15-1.5 | 15 | / | / | 1.5 | 230 | 50/60 | 8 | 80 | G1/2 |
 |
Basic 20-6SN | 20 | 1.8 | 3.6 | 6 | 115/230 | 50/60 | 100/70/55 | 130/150 | G1 |
 |
Mega S 40-12F | 40 | 14 | 7 | 12 | 220~240 | 50/60 | 460 | 291 | DN40/Flange |
 |
Master SD 20-4 | 20 | 1.6 | 2 | 4 | 220~240 | 50/60 | 25 | 130 | G1 |
|
Mega S 40-15F | 40 | 16 | 9 | 15 | 220~240 | 50/60 | 680 | 291 | DN40/Flange |
 |
Master SD 20-5 | 20 | 1.7 | 3.2 | 5 | 220~240 | 50/60 | 33 | 130 | G1 |
 |
Mega S 40-20F | 40 | 15.8 | 10.8 | 20 | 230 | 50/60 | 750 | 377 | DN40/Flange |
 |
Master SD 20-6 | 20 | 2 | 3.2 | 6 | 220~240 | 50/60 | 39 | 130 | G1 |
 |
Mega S 50-12F | 50 | 29 | 6.5 | 12 | 220~240 | 50/60 | 600 | 280 | /Flange |
 |
Master SD 20-7 | 20 | 2.2 | 4 | 6 | 220~240 | 50/60 | 52 | 130 | G1 |
|
Mega S 50-15F | 50 | 20 | 7 | 15 | 220~240 | 50/60 | 680 | 280 | /Flange |
 |
Master SD 20-7.5 | 20 | 2.2 | 4.5 | 7.5 | 220~240 | 50/60 | 60 | 130 | G1 |
 |
Master SD 25-4 | 25 | 1.8 | 2 | 4 | 220~240 | 50/60 | 25 | 130/180 | G1 1/2 |
|
Mega S 50-18F | 50 | 20 | 7.6 | 18 | 230 | 50/60 | 750 | 280 | /Flange |
|
Mega S 65-8F | 65 | 23 | 6.5 | 5 | 220~240 | 50/60 | 500 | 250 | /Flange |
 |
Master SD 25-5 | 20 | 2 | 2.7 | 5 | 220~240 | 50/60 | 33 | 130/180 | G1 1/2 |
|
Mega S 65-10F | 65 | 23 | 6.5 | 5 | 220~240 | 50/60 | 700 | 250 | /Flange |
 |
Master SD 25-6 | 25 | 2 | 3.5 | 6 | 220~240 | 50/60 | 39 | 130/180 | G1 1/2 |
